Waterproof 12V 24V 400mm adjustable stroke 3500N 770LBS load 5mm/s speed linear motion LA1035

Waterproof 12V 24V 400mm adjustable stroke 3500N 770LBS load 5mm s speed linear motion LA1035
Click to see details
Waterproof 12V 24V 400mm adjustable stroke 3500N 770LBS load 170mm s speed linear motion LA1035
100 % of buyers enjoyed this product!
Availability: in stock
Price:  US $54.66 / piece


from AliExpress

45 days Money back 45 days Money back Returns accepted if product not as described, buyer pays return shipping; or keep the product & agree refund with seller.
On-time Delivery On-time Delivery
Guarantees: On-time Delivery 60 days

Share:

HTB1cDkdpLuSBuNkHFqDq6xfhVXaT - Waterproof 12V 24V 400mm adjustable stroke 3500N 770LBS load 5mm/s speed linear motion LA1035

HTB1AuNoyf5TBuNjSspmq6yDRVXae - Waterproof 12V 24V 400mm adjustable stroke 3500N 770LBS load 5mm/s speed linear motion LA1035

HTB1NJa3KVXXXXXWapXXq6xXFXXX7 - Waterproof 12V 24V 400mm adjustable stroke 3500N 770LBS load 5mm/s speed linear motion LA1035

HTB1wZc4bBgXBuNjt hNq6yEiFXap - Waterproof 12V 24V 400mm adjustable stroke 3500N 770LBS load 5mm/s speed linear motion LA1035

waterproof 12V 24V DC 3500N=350KG=770LBS load 5mm/sec=0.2inch/sec speed 400mm stroke heavy duty linear motion LA1035

1 Type LA1035 with metal gear

2 Input 12V/24V DC

3 Load 3500N=350KG=770LBS

4 Speed 5mm/sec=0.2inch/sec

5 Limited switch With

6 Duty cycle 25%

7 Inner tube material Aluminum Alloy

8 Stroke length 400mm

9 Color Black

10Operation temperature -26 ~ +65 degree

Advantage:

More than 15 year experience,smart size,heavy duty motor.

Drawing:

HTB1jeA8xYGYBuNjy0Foq6AiBFXaB - Waterproof 12V 24V 400mm adjustable stroke 3500N 770LBS load 5mm/s speed linear motion LA1035

1. Retracted length=Lmin=120+Stroke=120+400=520mm

Lmin means the length when linear actuator 100% fully retracts, meanwhile,it will touch the tail limited switch and stop automatically,very safe.

2. Stroke means the movement length of linear actuator.

3. Lmax=Lmin+Stroke=520+400=920mm

Lmax means the length when linear actuator 100% fully extends, meanwhile,it will touch the head limited switch and stop automatically,very safe.

HTB1drT3iBjTBKNjSZFNq6ysFXXae - Waterproof 12V 24V 400mm adjustable stroke 3500N 770LBS load 5mm/s speed linear motion LA1035

Fast order link

Customized service:

1. Input : 12V or 24V or 36V or 48V

2. Load : 100N or 100KG or 220LBS and so on

3. Speed : 5mm/sec or 10mm/sec or 1inch/sec or 4inch/sec and so on

4. Stroke : 50mm or 200mm or 1000mm 4inch or 16inch or 40inch and so on

5. Rectracted Length=Lmin : The 100% fully retracted length

6. Cable length : 1m or 2m or 20inch or 40inch and so on

7. Customer’s special requirement
